1" NPT 0-25 SCFM (43 SM3/Hr) and Temperature

Specifications

• Choose Material 316 SS, 6061 T6 Aluminum or Nylon 6/6
• Choose Air Flow ranges 0- 10, 15, 20, and 0-25 SCFM. Custom flows available, just note what you need.
• Accuracy: +/- 1% of reading plus +/-0.5% of full scale
• Repeatability of +/- 0.2% of full scale
• 1” MNPT Pipe size
• OLED Display
• Measures any inert gas and any non-condensing clean gas
• Flammable gases: methane, propane, digester gas, natural gas
• 100:1 turndown
• Temperature:
• Gas: -40°F (-40°C) to 350°F (200°C)
• Ambient: -40° F to 120° F (-40° C to 50° C)
• Adjustable Response time from .1 to 6 seconds to achieve 63% of final value
• Power Requirement: 18 to 30 VDC (regulated), 125 mA maximum;
• Wetted Materials: Nylon 6/6, 6061T6 Aluminum, & 316 stainless-steel

• Output signals: Modbus RTU, USB-RS-232, 4–20 mA , 0–5 VDC, and User definable pulse output or frequency for totalized or flow rate indication
• Digital communications solutions include: Modbus RTU, USB, Bluetooth
• IP66 Enclosure
